Pre-approved subsidy ~30%
Available for solar systems to be installed on roofs of below categories of customers:
Residential
All types of buildings
Applicable states
Institutions
- Educational Institutions
- Schools
- Universities
- Health Institutions
- Hospitals
- Medical College
Type of System :
Grid-connected solar systems (without batteries)
System Sizes :
5kW, 10kW, 15kW, 20kW, 25kW
Features :
Included (remote Monitoring System + O & M for 5years)
Payback
★31/2 Years to 41/2 Years
Return on Investment
20% to 25%
Contact us
X
Enquire
KOTAK URJA SUNMAXX 100lpd
- Suitable for: Hard water applications
- Max. water hardness: 600ppm
- Max. pressure: 1 bar
- Inner tank: SS 304
 |
Offsets 1.5 tonnes of CO2/yr |
 |
Elec. bill savings: 1500 units/yr |
Item(s) not available at pincode:560001 Change
Additional Offers
-
Free Site Visit Provided Schedule Now
-
1 free service in 2 years
Chemical wash of tubes/Collector to remove deposits/scaling
Complete cleaning of hot water storage tank
Free replacement for broken tubes (upto 2 nos) - ETC Systems
Free replacement of Sacrificial Anode - FPC Systems
Free replacement of nuts/bolts/washers (if rusted)
Discounted prices on spares replacement
Exclusions: Tank leakages, faulty plumbing, manual damages
-
FPC exchange offer upto Rs /-
-
Complete plumbing support provided at extra cost
Why Us?
100% Original Products
Free Delivery & Installation
Manufacturer Warranty
After-sales Support
Specifications
- Product Specifications
- Tank Specifications
- Collector Specifications
- Warranty Details
- Certifications
- Features
- In the Box
- Reviews
Product Specifications
| Brand | |
|---|---|
| Type of Collector | Evacuated Tube Collector (ETC) |
| Tank capacity (litres) | 100 |
| Type of Application | Non-Pressurized Application |
| Maximum water TDS | Upto 600ppm |
| Approx. Floor Area required (NS * EW) | 2.2m * 1.0m |
| Est. Carbon savings | Offsets 1.5 tonnes of CO2/yr |
| Est. Electricity savings | Elec. bill savings: 1500 units/yr |
Tank Specifications
| Inner tank | SS 304 |
|---|---|
| Tank orientation | Horizontal |
| Tube fixing with tank | Direct Coupling |
| Tank insulation | 50 mm PUF, CFC free |
| Tank protection | Sacrificial anode (Magnesium) |
| Electrical back-up heater | Optional (2KW, with thermostat control) at extra cost |
| Supporting structure | Mild Steel (powder coated) |
| Heat Exchanger | No |
| Expansion Tank Provided | No |
Collector Specifications
| Number of tubes | 12 | ||||
|---|---|---|---|---|---|
| Collector area (sq m) | 1.97 | ||||
| Absorber material/coating | Selective three layer coating (AlN/SS/Cu) | ||||
| Collector features |
|
Warranty Details
| System performance warranty (years) | |
|---|---|
| Tank warranty (years) | 1 |
| Electrical heater (if provided) (years) | 1 |
| Warranty Inclusions/Exclusions | The warranty excludes consumables (sacrificial anode, hose pipe) and tube breakage |
| Warranty Type |
Certifications
| Product Certification | MNRE Approved |
|---|---|
| Manufacturer Certification | ISO 9001:2000, ISO 14001 |
Features
| Product Features |
|
|---|
In the Box
| In the box |
|---|
Reviews
