LIVGUARD SOLAR UPS SUPS241700 1500VA (24V)

0 Reviews

|Add to Compare

Loads: Lights, Fans, TV, PC, Mixie
Sine wave
Requires 2 batteries
Warranty: 2 years

Item(s) not available at pincode:560001 Change

Delivery Charge: Free

OR Submit Enquiry

Quick links

Specifications Features Warranty Details

Why Us?

100% Original Products

Free Delivery & Installation

Manufacturer Warranty

After-sales Support

Specifications

Product Specifications

Brand	Livguard
Power Output	AC
Phase Type	1-Phase Input 1-Phase Output
Topology	Offline/Standby
Inverter Capacity (VA)	1500
Capacity (W)	1200
Max. Input Voltage (V)	50
Waveform type	Sine wave
Battery (Internal/External)	External
Battery Capacity	2 Nos. (60 AH - 300 AH)
System Voltage (DC)	24V
Recommended Applications	Sensitive electronics (Home theatre, audio system etc.), Lights, Fans, TV, PC, Mixie

Solar Specifications

Minimum Solar Capacity (Wp)

100

Maximum Solar Capacity (Wp)

800

Charge Controller Rating (A)

Charge Controller Type

PWM

Grid Charging Parameters

Parameter	Feature
Grid Charging Current	Grid charging can be enabled/disabled from the Switch
Fast Charging	Yes, Inbuilt highest rating solar charge controller

Other Features

Feature	Yes/No
Inverter Mode (for lights & fans) / UPS Mode (for sensitive equipments)	Yes
User settable Priority (Solar/Mains/Battery OR Solar/Battery/Mains)	Yes
LCD Display	Yes
App for Remote Monitoring/Management	No

Features

UPS-Inverter switch
Home or Away switch
Variable voltage sensitivity setting	Not Applicable
Automatic Voltage Regulation (AVR)	Not Applicable
Full-time EMI/RFI suppression	Not Applicable
Frequency Regulation	Not Applicable
Data line surge protection	Not Applicable
Separate battery-protected and surge-only outlets	Not Applicable
Hot swap battery	Not applicable
Extendable battery back-up	Yes
Intelligent battery charging	Yes
Automatic battery self-test	Not Specified
Selectable charging current	Yes
Generator compatibility	Not Applicable
Cold start capability	Not Applicable
Audible Alarms	Yes
Bypass feature	Automatic
LED status indicators
LCD Display	Yes
Power Management software
Computer interface

Technical Specifications

Input

Modes of operation	Inverter Mode (For Lights & Fans) UPS Mode (For sensitive electronics)
Input voltage/frequency	230V AC/ 50 Hz
Voltage window for "on mains" operation	180-260Vac 100-290Vac
Voltage window for "on solar array" operation	60-130Vac
Maximum input voltage without damage	300Vac

Output

Waveform

Sine wave

Output voltage

On Mains:

Inverter Mode : 100-290Vac (mains voltage is passed to load)
UPS mode : 180-260Vac

On Battery:

230Vac (depending on load)

Output frequency

On Mains: 50Hz (Auto-detect)

On Battery: 50Hz +/-1Hz

Battery/Battery charger

Internal/External	External
Nominal voltage	24V
Battery capacity (C20)	2 Nos. (60 AH - 300 AH)
Battery type	Tubular, Flat Plate, SMF (VRLA)
Charger type	PWM
Charging current	Selectable, Max: 50A
Typical recharge time	10-12 hours
